Ice-O-Matic CIM0520HA90 Buying Guide: Current Specs, Output, Bins and Installation
Quick answer
The Ice-O-Matic CIM0520HA90 is a 22.25-inch air-cooled half-cube modular head rated for 525 lb/day at 70F/50F and 400 lb/day at 90F/70F. Its narrow cabinet, B42 direct-fit bin option, R290 refrigerant and front-service design make it a strong 500 lb-class choice where width and cleanability matter.
Key Specifications
|
Specification |
Current verified detail |
|---|---|
|
Machine style |
Air-cooled modular head |
|
Ice type |
Half cube; 3/8 x 7/8 x 7/8 in. |
|
Production - 70F air / 50F water |
525 lb per 24 hours |
|
Production - 90F air / 70F water |
400 lb per 24 hours |
|
Dimensions |
22.25 W x 24.25 D x 21.25 H in. |
|
Electrical |
115V/60/1; 11.9A minimum circuit ampacity; 20A max breaker |
|
Energy use |
3.7 kWh/100 lb at 70/50; 5.43 kWh/100 lb at 90/70 |
|
Potable water use |
17 gal per 100 lb at 90/70 |
|
Refrigerant |
R290A; 130 g charge |
|
Suggested bins |
B42 direct fit; B40/B55 use KBT19; B110 uses KBT23C; additional bins shown in current spec sheet |
|
Filtration |
IFQ1-XL manifold with IOMQXL replacement cartridge listed by manufacturer |
Use the current spec sheet, not an old output number
Ice machine listings can stay online long after a specification revision. For the CIM0520HA90, the current Ice-O-Matic sheet revised in October 2025 lists 525 lb/day at 70F air/50F water and 400 lb/day at 90F air/70F water. Those are the numbers this article and product page should use.
The 400 lb warm-condition rating is especially important for restaurants. It is 125 lb below the ideal-condition rating, showing why a nominal 500 lb label can overstate the production you should plan around in a hot kitchen.
A 22-inch head in the 500 lb class
The cabinet measures 22.25 inches wide, 24.25 inches deep and 21.25 inches high. That gives buyers a high-output modular option without committing 30 inches of line width. For replacement jobs, the narrow cabinet can also make it easier to work within an existing bin or equipment layout.
Always evaluate total installed dimensions, not head width alone. A wider storage bin may require an adapter kit, and the final height with bin, legs and machine head can be much taller than the 21.25-inch head dimension.
Half-cube ice and beverage applications
The CIM0520HA90 makes half cubes measuring about 3/8 x 7/8 x 7/8 inch. Half cube packs tightly into cups and works well for fountain beverages, water, tea, quick-service restaurants and high-volume foodservice where fast cooling and efficient cup fill matter.
If the menu is built around slow dilution in premium spirits, a larger cube or gourmet format may be better. If customers specifically ask for soft, chewable ice, compare nugget machines instead.
Bin compatibility is unusually clear on the manufacturer sheet
Ice-O-Matic lists a useful combination table for this exact model. The 22-inch B42 bin is shown as a no-adapter fit. The 30-inch B40 and B55 combinations use KBT19, while the wider B110 uses KBT23C. Larger bins are also listed, with their required kits identified in the specification.
That means a buyer can choose storage based on peak demand instead of guessing from cabinet width. Confirm the exact combination and adapter before ordering, especially when pairing the head with an existing bin or beverage dispenser.
Cleaning and service design
The Elevation Series uses a front-facing evaporator and removable components that Ice-O-Matic says are dishwasher safe up to 180F. Harvest Assist is designed to support consistent harvest and production, while electroless nickel plating protects the evaporator plates.
These features reduce friction during cleaning, but they do not eliminate cleaning or descaling. Water quality, filter replacement and food-zone sanitation still have a direct effect on performance and ice quality.
Electrical, water and operating limits
The current sheet lists 115V/60/1 power, 11.9A minimum circuit ampacity and a maximum 20A breaker. Operating limits are 50-100F ambient air, 40-100F water and 20-80 psig water pressure. The machine uses R290A refrigerant.
Ice-O-Matic also lists IFQ1-XL filtration with the IOMQXL replacement cartridge. The current specification notes enhanced evaporator warranty terms for qualifying filter-program enrollment; buyers should verify current program requirements at the time of purchase.
Who should choose CIM0520HA90?
Shortlist this model if you need a narrow, modular half-cube machine and your warm-condition demand fits comfortably below 400 lb/day after adding reserve. It is particularly attractive when a 22-inch B42 bin or narrow machine footprint solves a space problem.
If your warm-condition demand is closer to the mid-400s or above, compare larger heads rather than sizing from the 525 lb ideal-condition headline.
CIM0520HA90 FAQ
How much ice does Ice-O-Matic CIM0520HA90 make?
The current manufacturer specification lists 525 lb/day at 70F/50F and 400 lb/day at 90F/70F.
What size is CIM0520HA90?
The head is 22.25 inches wide, 24.25 inches deep and 21.25 inches high.
What bin fits CIM0520HA90 without an adapter?
The current manufacturer combination table shows B42 as a direct fit. B40 and B55 use KBT19; B110 uses KBT23C.
What ice shape does CIM0520HA90 make?
It makes half-cube ice approximately 3/8 x 7/8 x 7/8 inch.
What water filter does Ice-O-Matic list for this model?
The spec sheet lists the IFQ1-XL manifold system with IOMQXL replacement cartridge.
Does CIM0520HA90 use R290?
Yes. The current specification lists R290A refrigerant with a 130 g charge.
Buying takeaway
Choose this model when you need a narrow 22.25-inch half-cube head, clear bin compatibility, and roughly 400 lb/day of warm-condition capacity.
Shop the Ice-O-Matic CIM0520HA90 or contact the Ice Maker Supply equipment team for sizing, bin and installation guidance.
